Specifications
System Requirements
Operating Environment
* You can scroll this table sideways.
| Computer | PC running Windows |
|---|---|
| OS *1 | Windows 11 version 22H2 |
| Windows 10 version 22H2 | |
| Windows 8/8.1 | |
| Windows 7 | |
| Windows Server 2022 | |
| Windows Server 2019 | |
| Windows Server 2016 | |
| Windows Server 2012 (R2) | |
| Windows Server 2008 (R2) | |
| Windows Vista | |
| HD | Min. 30MB |
| MEMORY | Min. 1GB |
| Communication Port | Ethernet port adapter |
| Serial port | |
| PC Interface Board (only for Melsec Board version) | |
| Compatible InTouch Version | DAServer is used with Wonderware InTouch over 8 or IAS over 1.0 or Historian over 8.0 (FactorySuite A2). |
*1 You may need Wonderware patch files for full OS support.
Main parameters
General SPEC
* You can scroll this table sideways.
| Max. Adapters | 62 Adapters |
|---|---|
| Max. PLC Connections | 62 PLCs |
| Max. Tag points | No limit |
| Run as Windows Service | Supported |
| Protocol | SuiteLink, DDE, OPCDA2.05A |
| Alias name of Tag | Supported |
| Simulation | Supported |
OPC Interface
※この表は横にスクロールできます
| Program ID | Takebishi.MelsecEthernet.1 etc |
|---|---|
| Data Type | VT_BOOL (Boolean) |
| VT_I1 (8bit signed integer) | |
| VT_UI1 (8bit unsigned integer) | |
| VT_I2 (16bit signed integer) | |
| VT_UI2 (16bit unsigned integer) | |
| VT_I4 (32bit signed integer) | |
| VT_UI4 (16bit unsigned integer) | |
| VT_R4 (32bit real) | |
| VT_I8 (64bit signed integer) | |
| VT_UI8 (64bit unsigned integer) | |
| VT_R8 (64bit real) | |
| VT_BSTR (String) |
DDE/SuiteLink I/F
* You can scroll this table sideways.
| Application Name | MelsecEthernet etc. |
|---|---|
| Topic Name | Any |
| Update Rate | Any |
Expanded Format
* You can scroll this table sideways.
| Boolean | ex: M100 = 0 (Internal Relay 100) |
|---|---|
| Bit Position in Word Device | ex: D1:15 = 1 (the 15th bit of D1) |
| 16bit signed integer (:W) | ex: D1:W = 32767 (Data Register 1) |
| 16bit unsigned integer (:U) | ex: D1:U = 65535 (Data Register 1) |
| 32bit signed integer (:D) | ex: D1:D = 2147483647 (32bit values of D1 and D2) |
| 16bit BCD (:B) | ex: D1:B = 0x1234 (BCD value of D1) |
| 32bit BCD (:C) | ex: D1:C = 0x12345678 (32bit BCD value of D1) |
| Floating Point (:R) | ex: D1:R = 9.876 (32bit float of D1 and D2) |
| Character String (:Snn) | ex: D1:S10 = "ABCDEF･･･" (String from D1 to D10) |
| Text Decimal (:Ann) | ex: D1:A10 = "32767, 255, -1, ･･･" (Comma separated values in Decimal) |
| Text Hexadecimal (:Hnn) | ex: D1:H10 = "FFFF00001234･･･" (Text in Hexadecimal of 4 digit per 1 register) |
| Batch File Write (:Fnn) | ex: D1:F10 = "C:\test.csv" (Batche Write to D1-D10) |
